1. Product Features
The solar powered pest detection and reporting lamp is specially developed for agricultural and forestry pest detection and reporting. Automatically complete system operations such as trapping, killing, collecting, packaging, and drainage without supervision. Widely used in agriculture, forestry, animal husbandry, vegetables, tobacco, tea, medicinal herbs, gardens, orchards, urban greening, quarantine and other fields.
2. Performance Characteristics
1. Comply with the GB/T24689.1-2009 Pest Detection and Reporting Lamp Standard.
2. Adopting a stainless steel overall structure.
3. Utilize optical, electrical, and CNC technologies for automatic control.
4. Insect body treatment method: Three layers of filter screen are used to separate the insect body, and medicine fumigation treatment is used.
5. Automatically turn on the lights at night, turn off the lights during the day (standby), and change the working state at night without being exposed to instantaneous strong light.
6. Additional time period control can be added: according to the living habits of target pests, set the working time period.
7. Rain control device switch: Automatically discharge rainwater, effectively separating rain and insects.
8. Lightning protection device: effectively prevents lightning strikes.
3. Technical Parameter
1. Working voltage: DC12V
2. Insect trapping light source: 20W dedicated insect trapping light tube (main wavelength 365nm)
3. Solar panel power: ≥ 40W (selected based on local light irradiation intensity to ensure battery service life)
4. Battery: DC12V 24Ah/maintenance free (based on lamp body loss, working for 6 hours per day, can work normally in rainy weather for three consecutive days)
5. Power consumption: standby state ≤ 35W
6. Impact screen: at a 120 degree angle to each other, single screen size: length 595 ± 2mm, width 213 ± 2mm, thickness 5mm
7. Lamp start performance: Start within 5s
8. Insulation resistance: ≥ 2.5M Ω
9. Lamp body size: 650mm × 650mm × 2000mm
10. Design life ≥ 10 years
