1. Product Features
The intelligent pest detection and reporting lamp is specially developed for agricultural and forestry pest detection and reporting. This lamp utilizes modern light, electricity, and CNC technology to achieve functions such as automatic processing of insect far infrared, automatic conversion of insect receiving bags, and automatic operation of the entire lamp. Automatically complete system operations such as trapping, killing, collecting, packaging, and drainage without supervision. Multiple sensor interfaces such as wind speed and direction, environmental temperature and humidity, and lighting can be added, and data can be uploaded through GPRS to monitor the relationship between the environment and pests and diseases. Widely used in agriculture, forestry, animal husbandry, vegetables, tobacco, tea, medicinal herbs, gardens, orchards, urban greening, quarantine and other fields.
2. Performance Characteristics
1. Adopting optical, electrical, and CNC technologies for automatic control.
2. The test report light is equipped with a 1200W pixel camera image acquisition device, which can collect real-time image information inside the insect box through the camera. Parameters such as photography and work mode can be set remotely through the platform.
3. The instrument is equipped with a built-in counting device, which can record the number of insects in real-time and upload them to the platform.
4. Remote wireless photography and control functions such as turning on and off lights and transferring storage.
5. Both remote automatic and manual photography are available.
6. Adopting a stainless steel overall structure.
7. Color 7-inch LCD touch screen control, LED display of environmental temperature, humidity, and time.
8. It can be controlled by different time periods, with automatic and manual warehouse transfers available.
9. You can also manually control functions such as warehouse transfer, insect trap light switch, heating tube switch, pest control warehouse, and drying warehouse emptying.
10. The automatic conversion of the insect catcher and the eight bit automatic conversion system ensure that the insects captured during 8 time periods are not confused.
11. The upper and lower layers of far-infrared insect body treatment warehouses are more effective in completing pest control and drying work.
12. Temperature control of far-infrared insect body treatment warehouse: After working for 15 minutes, it reaches 85 ± 5 ℃, and the treatment time can be adjusted arbitrarily.
13. The Case fatality rate of far-infrared insect treatment is not less than 98%, and the insect integrity rate is not less than 95%.
14. Far infrared insect body treatment and daily storage (no need for poison bottles).
15. Automatically turn on the lights at night, turn off the lights during the day (standby), and change the working state at night without being exposed to instantaneous strong light.
16. Time period control: Set the working time period based on the living habits of target pests.
17. Rain control device switch: Automatically discharge rainwater, effectively separating rain and insects, and can also add automatic control of working status based on changes in external rainfall.
18. Power supply system, 220V mains supply.
19. Lightning protection device: effectively prevents lightning strikes.
20. Multiple environmental parameter interfaces such as wind speed and direction, ground temperature and humidity, lighting, rainfall, etc. can be added.
21. With built-in GPS positioning function, you can view data such as device sites in the map, and track stolen devices.
22. Network mode: 4G WIFI wired can be selected at will.
3. Technical Parameter
1. Power supply: Applicable power supply voltage AC220V ± 60V. The power stabilizer isolator can ensure the output voltage AC220V ± 5V
2. Power consumption: standby state ≤ 5W; Whole lamp power ≤ 450W
3. Insect trap light source: 20W black light tube (main wavelength 365nm)
4. Impact screen: at a 120 degree angle to each other, single screen size: length 595 ± 2mm, width 213 ± 2mm, thickness 5mm
5. Lamp start performance: Start within 5s
6. Temperature control of far-infrared insect body treatment warehouse: reach 85 ± 5 ℃ after working for 15 minutes
7. Insulation resistance: ≥ 2.5M Ω
8. Lamp body size: 650mm × 650mm × 2000mm
9. Design life ≥ 10 years
