1. Product Features
The mobile disease and pest epidemic monitoring and reporting station is an integrated intelligent monitoring equipment designed specifically for disease and pest monitoring. Compared to traditional single equipment for disease, pest, and meteorological monitoring, this equipment integrates commonly used disease and pest monitoring equipment organically. It integrates disease monitoring, pest monitoring, meteorological monitoring, and video monitoring, which is conducive to studying the correlation between disease and pest incidence trends and the meteorological environment. At the same time, it avoids the tedious installation of various devices. Mainly suitable for intelligent monitoring of agricultural and forestry pests and diseases.
2. Performance Characteristics
1. Stainless steel spray design shell, ergonomic design, beautiful and generous.
2. 15 inch ultra large high-definition capacitive touch screen, Windows operating system, with good human-computer interaction interface.
3. It has monitoring modules such as disease monitoring, pest monitoring, meteorological monitoring, and video monitoring.
4. Equipped with a 12 megapixel high-definition microscope camera for disease conditions and a 12 megapixel industrial camera for pest control, it can continuously monitor relevant information such as diseases and pests 24 hours a day and upload it to the cloud platform. Users can view monitoring data and control monitoring devices through PC and APP terminals.
5. Fully automatic operation can minimize human intervention and improve work efficiency.
6. The built-in GPS positioning function allows you to view the current geographic location information on the map.
7. Time sharing work: The working hours can be set based on the activity habits of target pathogen spores. Equipped with rain control function, the equipment working status can be adjusted according to weather conditions.
8. It can output device operation status information to facilitate remote monitoring of device operation status by the central platform.
3. Technical Parameter
1. Material: GB32080-92 stainless steel
2. Data transmission method: 5G, wired network
3. Data collection method: remote network platform manual control collection, and device timed automatic collection
4. Power supply voltage: AC 220V ± 5%
5. Power: 600W
6. Slide: 365 slides can be added at a time and can be used for 365 days, one slide per day
7. Insect receiving bottles: 8 insect receiving bottles can ensure that the insect bodies are not mixed up every day
8. Insulation resistance: ≥ 2.5M Ω
9. Design life: 5 years
10. Working environment temperature: -20-70 ℃
