1. Product Features
Insect killing lamp is a physical control method that uses Phototaxis of pests to trap and kill. Frequency vibration insecticidal lamp is a device that utilizes the strong phototaxis, wave taxis, color taxis, and sexual information of pests. The wavelength, band, and frequency of the light are set within a specific range, and the sexual information generated by the pests is lured into the lamp by using light at close range and wave at long distance. The lamp is equipped with a frequency vibration high-voltage power grid to contact and kill the pests, causing them to fall into the insect receiving bag under the lamp, achieving the goal of killing the pests. Widely used in agriculture, forestry, vegetables, warehousing, tea, tobacco, gardens, scenic spots, parks, schools, enterprises and institutions, greenhouses, vineyards, aquaculture, animal husbandry, etc.
2. Performance Characteristics
1. Adopting frequency vibration control technology, it complies with the national standard of frequency vibration insecticidal lamps for plant protection machinery GB/T24689.2-2009.
2. The high-voltage power grid is made of arc resistant coating material, with a wire diameter of 0.6mm or 2mm. The insecticidal net is wound horizontally or connected vertically.
3. Equipped with an overcurrent and short circuit protection device for the power grid to prevent short circuits caused by residual insects.
4. The net spacing can be selected based on different target pests (generally ≤ 10mm).
5. According to the living habits of different target pests, automatic segmented (hourly) lure and control devices can be added.
6. Insulating column: Instantaneous high temperature resistance of 1000 ℃, corrosion resistance, high voltage resistance, continuous arcing of high-voltage power grid for 30 minutes on rainy days, and no carbonization phenomenon on the insulation column.
7. Light control technology: It can automatically turn on and off the lights according to the day and night.
8. Rain control technology: When the environmental humidity is greater than 95% RH, the frequency light can enter the automatic protection state. When the environmental humidity is not greater than 95% RH, it can automatically return to normal operation.
9. Lamp pole height: Made of high-quality stainless steel pipes, with a total height of 3 meters. Adjustable height with an adjustable range of 0.5 meters (optional).
3. Technical Parameter
1. Trap light source: Able to configure different wavelengths of trap light sources with frequency oscillation 1 # -20 #, and the length of frequency oscillation light tube T8/T9 is 420mm
2. Frequency light color: yellow; Insect catching bag: red, size: 250 × three hundred and seventy × 370mm
3. Solar cell module material: monocrystalline silicon, solar panel power: ≥ 40W, size 630mm × 550mm × 30mm
4. Battery: DC12V 24Ah/maintenance free (works for 6 hours per day and can work normally in rainy weather for three consecutive days)
Size 165 * 125 * 175 mm
5. Working voltage: DC12V
6. Insulation resistance: ≥ 2.5M Ω
7. Whole lamp power: ≤ 35W
8. Lamp power: 15W multi wavelength insect trap lamp, ballast instantly activated
9. Lamp start time: ≤ 5s
10. Impact area: ≥ 0.15 ㎡
11. Grid voltage: ≥ 2300 ± 115V
12. Control area: 40-60 acres
13. Design life: ≥ 15 years
14. Lamp body size: 300 × three hundred × 630mm (excluding edges)
15. Packaging size: 320 × three hundred and twenty × 710mm, net weight of lamp body: ≤ 4kg
16. Other intelligent IoT functions can be extended according to user needs.
