1. Product Features
Insect killing lamp is a physical control method that uses Phototaxis of pests to trap and kill. Frequency vibration insecticidal lamp is a device that utilizes the strong phototaxis, wave taxis, color taxis, and sexual information of pests. The wavelength, band, and frequency of the light are set within a specific range, and the sexual information generated by the pests is lured into the lamp by using light at close range and wave at long distance. The lamp is equipped with a frequency vibration high-voltage power grid to contact and kill the pests, causing them to fall into the insect receiving bag under the lamp, achieving the goal of killing the pests. Widely used in agriculture, forestry, vegetables, warehousing, tea, tobacco, gardens, scenic spots, parks, schools, enterprises and institutions, greenhouses, vineyards, aquaculture, animal husbandry, etc.
2. Performance Characteristics
1. Adopting frequency vibration control technology, it complies with the national standard of frequency vibration insecticidal lamps for plant protection machinery GB/T24689.2-2009.
2. The high-voltage power grid is made of arc resistant coating material, with a wire diameter of 0.6mm or 2mm. The insecticidal net is wound horizontally or connected vertically.
3. Equipped with an overcurrent and short circuit protection device for the power grid to prevent short circuits caused by residual insects.
4. The net spacing can be selected based on different target pests (generally ≤ 10mm).
5. According to the living habits of different target pests, automatic segmented (hourly) lure and control devices can be added.
6. Insulating column: Instantaneous high temperature resistance of 1000 ℃, corrosion resistance, high voltage resistance, continuous arcing of high-voltage power grid for 30 minutes on rainy days, and no carbonization phenomenon on the insulation column.
7. Light control technology: It can automatically turn on and off the lights according to the day and night.
8. Rain control technology: When the environmental humidity is greater than 95% RH, the frequency light can enter the automatic protection state. When the environmental humidity is not greater than 95% RH, it can automatically return to normal operation.
9. Galaxy effective radius of single lamp: not less than 120M in farmland area and 80M in forest area.
3. Technical Parameter
1. Trapping light source: frequency oscillator tube (wavelength 320-680nm)
2. Frequency light color: yellow; Insect catching bag: red
3. Power supply voltage: AC 220V/50Hz or DC 12V
4. When the lamp voltage is 200-280V, the lamp start time is ≤ 5s
When the lamp voltage is 160-200V, the lamp start time is ≤ 15s
5. Power: ≤ 35W
6. Insulation resistance: ≥ 2.5M Ω
7. Light source: 15W multi wavelength insect trap tube, ballast instantly activated
8. Impact area: ≥ 0.15 ㎡
9. Grid voltage: ≥ 2300V
10. Packaging size: 320 × three hundred and twenty × 710mm, net weight of lamp body: ≤ 4kg
11. Lamp body size: 300 × three hundred × 630mm (excluding edges)
12. Design life: ≥ 5 years
13. Insect catching bag size: 250 × three hundred and seventy × 370mm
