1. Product Features
Rice thrips harm rice leaves, affect rice photosynthesis, and cause a decrease in yield. The rice thrip detection and reporting instrument is developed based on the principle that rice thrips are sensitive to specific colors. The equipment integrates automatic adjustment of the color plate height, automatic rotation, automatic photography, and automatic data uploading, and is widely used in the field of agricultural rice planting.
2. Performance Characteristics
1. Adopting optical, electrical, and CNC technologies for automatic control.
2. Color 7-inch Chinese LCD capacitive touch screen operation; It can be set and controlled in different time periods, and can be taken automatically or manually; Intelligent control of Android system, displaying environmental temperature, humidity, and time.
3. Configure a 1200W pixel image acquisition device that can collect real-time insect information on the color palette through the camera. The captured image clarity can meet the requirements for manually identifying insect species.
4. Equipped with a adjustable bait device that can automatically or manually raise or lower the bait height of the color palette.
5. Various parameters of the instrument can be remotely configured through the server, making it easy to maintain and manage.
6. With built-in GPS or Beidou positioning function, you can view data such as device sites in the map.
7. Power supply method: Solar power supply, using solar energy in combination with batteries (DC type).
8. Network mode: Multiple networking methods available, including 4G, WIFI, and wired, allowing for anytime, anywhere network management.
9. Device data can be viewed through various methods such as PC and APP.
3. Technical Parameter
1. Power supply: solar panel power: 60W, battery specification: 12V 24AH
2. Power consumption: ≤ 50W
3. Insect trapping device: color palette
4. Insulation resistance: ≥ 2.5 M Ω
