1. Product Features
The spore trap can detect the spores and pollen dust particles of disease pathogens that flow and spread with the air. It is mainly used to monitor the stock and diffusion dynamics of disease spores, providing reliable data for predicting and preventing disease epidemics and infections. It is a specialized equipment for monitoring crop diseases that should be equipped by the agricultural plant protection department.
2. Performance Characteristics
1. Comply with the GB/T 24689.3-2009 standard for plant protection machinery spore catchers.
2. Compatible with ATCSP pest detection and prevention system.
3. It can be fixed within the reporting area and observed at fixed points for specific spore types and quantities.
4. Can work continuously, with adjustable timing.
3. Technical Parameter
1. Material: GB32080-92 stainless steel
2. Power supply voltage: AC 220V ± 5%
3. Power: 180W
4. Timing: 10 time periods can be set
5. Air speed at the gas gathering port: 0.3~5 m/s
6. Specification of glass slide: length: 76.2mm; Width: 25.4mm; Thickness: 1-1.2mm
7. Insulation resistance: ≥ 2.5M Ω
8. Design life: 5 years
