1. Product Features
The intelligent water and fertilizer integrated machine realizes automatic irrigation and fertilizer application, achieving automatic management and distribution of water and fertilizer supply. The system injects various fertilizers into the irrigation pipeline in a timely, appropriate and proportional manner based on the user set fertilization ratio, fertilization time, fertilization ratio and cycle mode, EC/pH balance, and other relevant conditions, automatically completing the fertilization and irrigation task, and reasonably controlling the water and fertilizer supply. Make fertilization and irrigation more scientific and convenient, and improve management level. Integrate the latest irrigation control technology with economic practicality.
2. Performance characteristics
1. It can be controlled by mobile phones or computers, directly connected to the internet through wired or wireless, and connected to 4G wireless communication.
2. Three fertilization channels, each equipped with a flow meter device, can display the current fertilization flow rate, with a single channel absorbing up to 600L/H.
3. Power supply system 220V, stainless steel booster fertilizer pump, power 1.1kw, flow 6m ³/ h. Head 55m, maximum pressure 0.5Mpa
4. 10 inch touch screen control, Chinese human-machine interface display, with functions such as data collection and storage, device control, remote access, etc;
5. The pipeline system adopts u-pvc, which is durable, corrosion resistant, UV resistant and anti-aging. All key components can be disassembled freely, and replacement of components is simple and convenient, with a one-year free warranty.
6. Management personnel can adjust parameters appropriately through the interface based on actual situations, and can also manage irrigation and fertilization with human intervention based on experience, which is highly operational.
7. The equipment comes with a pressure detection system and exhaust system to maximize output efficiency.
8. The head system can be remotely controlled, and the water pump frequency conversion cabinet can start and stop.
9. Support bus decoder, wireless Lora valve controller, wireless 4G valve controller, and field solenoid valve support wired and wireless access.
10. Supports multiple rotation irrigation settings, and can set the fertilization time, duration, and fertilization channel selection for each area.
11. Support the access of meteorological stations and moisture stations, and the monitored data can be displayed separately on the screen interface, with the ability to display meteorological change curves.
3. Technical Parameter
1. Overall size: 650 * 680 * 1100mm
2. Fertilizer suction pipeline: DN20
3. Water and fertilizer machine inlet and outlet pipeline: DN32
4. Flow rate: 6 cubic meters/h, lift: 55m
5. Water pump power: 1100W
6. Working pressure: 0-0.5 MPa
7. Working voltage: 220V
8. Fertilization channel: three channels
9. Screen size: 10 inches
10. Control method: mobile/local control
11. Field control mode: wired, wireless
