1. Product Introduction
The use of sticky insect boards can effectively control the initial number of pests, reduce pesticide use, protect the world, and promote biophysical control by following the pattern of pest occurrence. This product can be widely used in greenhouses, greenhouses, nurseries, outdoor land, gardens, orchards, livestock farms, and fruit and vegetable storage warehouses.
2. Characteristic
1. Double sided trapping
3. Quality Introduction
The board material can be reused, and the sticky insect glue is non-toxic, odorless, pollution-free, high in viscosity but does not flow, weather resistant, water resistant, UV resistant, and non curing after long-term use. PP material, with certain strength, hardness, moisture resistance, double-sided adhesive coating, and non curling layout. (No lamination, as lamination reduces the amount of adhesive and reduces the effectiveness of prevention and control).
4. Type
Red board, yellow board, blue board, green board, pink board, purple board, white board, gray board, blackboard, green board.
5. Prevention and Control Targets
Red board: aphids, leaf beetles, cryptoptera, blind spring, mosquitoes, flies, leafhoppers, Diamondback moth
Yellow board: It can trap and kill whitefly, whitefly, striped flea, leafrope, aphid, thrips, spot rope, pear stem bee, whitefly, tea Jacobiasca formosana and many Fly pests.
Blue board: thrips, aphids, leaf beetles, blind spring, mosquitoes, flies, Pieris rapae, Diamondback moth
Green board: aphids, leaf beetles, cryptoptera, blind spring, mosquitoes, flies, leafhoppers, Diamondback moth, Huachun
Powder board: aphids, leaf beetles, cryptoptera, blind spring, mosquitoes, flies, leafhoppers, Diamondback moth, Yuanqing
Purple plate: aphids, leaf beetles, cryptoptera, blind spring, mosquitoes, flies, leafhoppers, Diamondback moth, hoppers, Pieris rapae
Whiteboard: aphids, leaf beetles, cryptoptera, blind spring, mosquitoes, flies, leafhoppers, Diamondback moth, hoppers, leaf miner
Gray board: aphids, leaf beetles, cryptoptera, blind spring, mosquitoes, flies, leafhoppers, Diamondback moth, Geometer moth
Blackboard: aphids, leaf beetles, cryptoptera, blind spring, mosquitoes, flies, leafhoppers, Diamondback moth
Green board: aphids, leaf beetles, cryptoptera, blind spring, mosquitoes, flies, leafhoppers, Diamondback moth
6. Technical Parameter
1. Comply with the GB/T24689.4-2009 standard for plant protection machinery insect traps (an inspection report issued by the National Agricultural Machinery Quality Supervision and Inspection Center that complies with the GB/T24689.4-2009 national standard must be provided).
2. Substrate material: PP material, with certain strength, hardness, moisture resistance, double-sided adhesive coating, and non curling of the board surface (without film covering, the amount of adhesive decreases due to film covering, and the prevention and control effect is reduced).
3. Substrate thickness: 0.3-0.35mm.
4. In an environment with a temperature of 10 ℃ to 70 ℃, the substrate has no obvious deformation, the colloid does not fluidize, and does not dissolve in water. In use, the color is consistent, and there is no significant color difference between the facing and backlighting surfaces under strong sunlight.
5. The substrate band consists of ten colors, including red, yellow, green, cyan, blue, purple, white, pink, gray, and black.
6. Substrate coating: Hot melt adhesive, acid resistant, alkali resistant, corrosion resistant, non-toxic, and odorless.
7. Equipped with hanging holes, the surface is flat and smooth, making it easy to hang and clean.
8. The substrate should be coated with adhesive on both sides, and the adhesive layer should be uniform and consistent. The thickness of the adhesive layer on one side should be 0.03-0.05mm, and there should be no delamination during disassembly.
9. The bonding force of the adhesive layer shall not be less than 6.8 × 10-4N/mm2.
10. Equipped with hanging holes, with a flat surface and a standard specification of 20cm × 25cm, 50 sheets/pack. (500 sheets per box).
7. Suspension Method
1. Different color plates can be selected according to the growth stages of different crops to prevent and control different pests, including seedling stage, planting stage, growth stage, and different color plates can also be selected for different environments.
2. When using, thread iron wire or rope into the two holes of the color board and hang it on objects such as supports or branches. The diameter of the support hanging in the field should not be too large to avoid affecting the armyworm.
3. The recommended height for hanging on plants is around 15-30cm from the top of the plant. When the growth point of vines or tall crops is close to the top of the shed, the color palette can be hung in the middle and upper part of the plant height.
4. Dosage: Use 15-20 large, 30-40 medium, and 60-120 small tablets per 667 square meters, or increase or decrease according to the occurrence of insect infestation. When used for monitoring, 5 standard sheds are hung per acre.
8. Reuse
1. When using too much dirt or sticky insects in the wild, it is necessary to clean and repaint.
2. When cleaning, please first use a screwdriver or scraper to remove the dirt on top, and then use xylene or gasoline to repeatedly clean with a brush.
3. After cleaning, be sure to air dry before applying glue.
4. When applying glue, due to the high viscosity of sticky insect glue, it should be first placed in water at around 80 ℃ for 30 minutes. After the glue melts, use a screwdriver or scraper to evenly scrape the glue onto the color board.
