1. Product Features
Remote real-time pest monitoring system is a new generation of automatic pest detection system. The system mainly uses electronic and mechanical technology, wireless transmission technology, Internet of Things technology, and biological Pheromone technology to build a set of pest monitoring and early warning system. This system integrates pest trapping and counting, environmental information collection, data transmission, and data analysis, achieving the automation and intelligence of targeted pest trapping, classification and statistics, real-time reporting, remote detection, and pest warning. It has the characteristics of stable performance, easy operation, and flexible settings, and can be widely used in monitoring fields such as agricultural pests, forestry pests, and storage pests.
2. Performance Characteristics
1. 7-inch full color touch screen, Android 5.1 operating system, full Chinese operation menu, simple and convenient operation.
2. Strong timeliness: Real time collection of pest numbers and environmental factors from each channel, and preservation and display. And information can be collected through GPRS upload according to the set upload cycle.
3. Complete information collection: The collected information includes relevant information such as the time, type, quantity, and monitoring points of the bait.
4. Improved information retrieval: The data storage function is powerful, enabling the storage of past year pest data. You can query pest related data from different years at any time, making the information retrieval function more convenient and comprehensive.
5. Real time data viewing: Detection data can be viewed through the APP or login platform, supporting report output. Reports and graphs can be queried and viewed by selecting time periods based on the type of bait, and reports can be printed through the computer.
6. Meteorological monitoring: It supports external meteorological sensors and is compatible with sensors including but not limited to air temperature, air humidity, wind speed, and wind direction, making it convenient for users to analyze the occurrence status of pests and the relationship between meteorology.
7. Diversified parameter settings: Users can set instrument parameters through the platform and APP.
8. Lightning protection device: can effectively prevent lightning strikes.
9. The solar power supply system is energy-saving, environmentally friendly, and convenient for outdoor work.
10. Supports WIFI, 4G, RJ45 communication interfaces.
3. Technical Parameter
1. Solar cell module material: monocrystalline silicon, solar panel power: ≥ 40W
2. Battery: DC12V 24Ah/maintenance free
3. Working voltage: DC12 V
4. Working temperature: -20 ℃~70 ℃ Working humidity: 0 ℃~98 ℃
5. Pest size: 2mm~20mm
6. Measurement accuracy: ≥ 95%
